Product Specification and Steel Grade

ASTM

JIS

AISI

EN

Mill's Standard

Specification

A240
SA240

G4304
G4312

10088-2
17224, 17440 , 17441

Grade

S30400
S30403
S31603
S43000

SUS304
SUS304L
SUS316L
SUS430

304
304L
316L
430

14301
1.4306
1.4401
1.4016

201
202
204Cu3

Available Size

　Width:610~2000 mm

　Thickness: 2.5~10.0 mm

　Inner Diameter: 610 +0/-5 mm

　Available Steel Grade: 201, 202, 304, 304L, 316L

Unit Weight Limitation

Unit: ton

3 feet

1M

4 feet

5 feet

300 series

3~17

3~18

3~22

3~23 (≦5.0) / 27 (>5.0)

400 series

3~20

Remark

Both Cut Edge and Mill Edge are available

Dimension and Shape Tolerance

Thickness Tolerance

Thickness

3 feet

1M / 4 feet

5 feet

2.00~2.49

±0.05 mm

±0.06 mm

2.50~3.14

±0.06 mm

±0.07 mm

±0.08 mm

3.15~3.99

±0.07 mm

±0.08 mm

±0.09 mm

4.00~4.99

±0.08 mm

±0.09 mm

±0.10 mm

5.00~5.99

±0.10 mm

±0.10 mm

±0.10 mm

6.00~7.99

±0.12 mm

±0.12 mm

±0.12 mm

* Aim Tolerance = 1/2 (lower limit + upper limit)

Width Tolerance: Mill Edge: Aim ±10 Cut Edge : Aim -0 / +1

Camber: Max. 5 mm / 2M

Telescope & Protruding Wraps: Mill Edge: 50 mm
　　　　　　　　　　　　　　　Cut Edge: 30 mm　

Edge Crack: Mill Edge: Max. 5 mm per side
　　　　　　Cut Edge: Not Allowed
